Old Man Emu – Coil Springs 2881 – Toyota Landcruiser 95 to 10/2002 LWB

Old Man Emu – Coil Springs 2881 – Toyota Landcruiser 95 to 10/2002 LWB

Pair of 2!

ARB designs an extensive range of Old Man Emu coil springs for each vehicle, using state of the art micro-alloyed spring steel to ensure superior resistance to sagging and corrosion. With such a wide range on offer, coil springs can be better matched to your specific load requirements and intended vehicle usage.

While ride height increases are attained, a great emphasis is placed on ride control improvements. Further fine tuning is achieved when the springs are matched to a corresponding set of Old Man Emu shock absorbers, delivering a fully integrated system designed specifically to suit your vehicle.



MATERIAL

Manufactured from state of the art micro-alloyed spring steel for superior strength and durability

MULTIPLE OPTIONS

Constant and variable rate coils available for multiple applications

FITMENT

Spring end configurations designed to exact specifications, guaranteeing perfect fitment to your vehicle

HARDENED FINISH

Finished in durable, hard wearing black powder coat

SHOT-PEENED

To reduce stress, which greatly enhances spring life.

DOUBLE-SCRAGGED

To eliminate spring sag.

VARIABLE AND CONSTANT RATE

Designs used to obtain optimum ride comfort and load-carrying capabilities.

COIL SPRUNG 9 STAGE VALVING

For optimum performance



Specifications:

Bar diameter (mm): 16

Free height (mm) A: 375

Free height (mm) B: 375

Number of turns: 10,2

Coil weight (kg): 4,7

Sprin rate (N/mm): 87

OE spring rate (lbs): 490



Suits:

Toyota Landcruiser 95 to 10/2002 LWB































Toyota 4 Runner / Surf 1996 – 2002













Toyota Tacoma V6 & 4 Cylinder 1998 – 2004
