Hi-Lift® – X-TREME Jack XT-485 122 cm

The Hi-Lift® X-TREME is for the serious Hi-Lift® user, offering the “top of the line” all-cast version (48″ or 60″ sizes) with a special top winch-clamp-spreader attachment that provides the ultimate in multi-use functionality.

The X-TREME Top Clamp replaces the top clamp-clevis of the standard Hi-Lift® models and provides the ability to winch, clamp, and spread up to 5,000 lbs.

Features

• All-Cast Construction
• 7000lb (3175.14kg) Tested Capacity
• Available in 48″, & 60″ Heights. (122, & 152cm)
• Lifts, Winches, Clamps, & More
• A must-have for the serious Hi-Lift user!
• Tested and certified to meet applicable requirements of ASME B30.1-2015

FEATURES

• Size: 122cm
• Min. Lift Height: 11.43cm
• Max. Lift Height: 98.12cm
• Overall Height: 128.91cm
• Width: 12.7cm
• Depth: 24.46cm
• Rated Load (RL): 2,113kg
• Tested Load (TL): 3,175kg
• Winching Capacity: 2,268kg
• Clamping Capacity: 2,268kg
• Weight: 12.77kg
